Yamaha / V MAX SHO
Yamaha VF150
The IBEX Award-winning In-Line Four V MAX SHO® 150 features an exhilarating top speed and a 7.7-second hole shot.
All Yamaha outboards
V MAX SHO
VF150
- Power
- 150 hp
- Configuration
- Inline 4
- Displacement
- 2.8L
- Weight
- 218 kg (480 lbs)
Authorizeddealer
View on Yamaha site dealerAbout this engine
The IBEX Award-winning In-Line Four V MAX SHO® 150 features an exhilarating top speed and a 7.7-second hole shot. Now that's signature V MAX SHO performance.*
Key features
- Quiet Power and Performance
- Midrange Power and Response
- Fuel Efficient
- Optimum Power
- Power Management
- AMPLE CHARGING POWER
- EASY RIGGING
- NEW Tilt Stop Lever
Full specifications
- Weight †
- 218 kg (480 lbs)
- Full Throttle RPM Range
- 5000 ~ 6000 rpm
- Fuel Induction System
- EFI
- Recommended Engine Oil
- Yamalube® 4M (See owner's manual)
- Engine Type
- Inline 4
- Displacement
- 2.8L
- Bore x Stroke
- 96 x 96.2mm (3.78 x 3.79in)
- Prop Shaft Horsepower
- 150 hp at 5500 rpm
- Alternator Output at W.O.T.
- 50 Amp
- Compression Ratio
- 10.3:1
- Recommended Fuel
- Octane 89
- Recommended Fuel Filtration
- Yamaha 10-Micron Fuel/Water Separating Filter (external)
- C.A.R.B. Rating
- 3-Star
- Exhaust
- Through Propeller
- Intake
- 16
- Ignition
- TCI Microcomputer
- Spark Plug
- LFR6A-11
- Starting System
- Electric
- Lubrication
- Wet Sump
- Engine Oil Capacity
- 4.5L/4.3L
- Recommended Cooling
- Thermostatic Control
- Ethanol Blend Limit
- 10% Maximum
- Gear Ratio
- 2.00:1
- Gear Shift
- Forward, Neutral, Reverse
- Shaft Length
- 20" - 25"
- Degree of Tilt
- 70°
- Degree of Trim
- -4° through +16°
- Mounting Centers
- N/A
- Steering
- Mechanical Remote
- Steering Angle (maximum)
- 32° from center, either direction
- Warranty
- Limited 3-Year Pleasure, 3-Year Government, 1-Year Commercial
