Honda BFP60

The BF60 is all about being the best.

All Honda outboards
Honda BFP60

Mid-Range

BFP60

Power
60 hp
Configuration
4-Stroke SOHC 3 Cylinder/12 Valves
Displacement
998 cc
Weight
256 lb
AuthorizedHondadealer
View on Honda site

About this engine

The BF60 is all about being the best. The best maneuverability and highest speed in its class. The best fuel economy. Best in class high output charging. And of course, best time out on the water. Available in two versions, the BF60 and the BFP60 Power Thrust offer powerful performance and exhilarating acceleration. The BFP60 offers a unique gear case and larger propeller that’s ideal for pontoons and larger hulled boats. The BFP60 also features Easy Dock Steering™; offering 50° of steering from port and to starboard, simplifying maneuvering in the marina. Add in features like BLAST, Programmable Fuel Injection, a high performance heavy-duty gear case, Lean Burn Control, and variable speed trolling, and you’ve got a legendary motor that’s truly best in class.

Key features

  • Instant Acceleration: Honda’s exclusive BLAST system improves acceleration at low speeds.
  • Power Thrust available: A unique gear case and larger propeller makes the Power Thrust BFP60 ideal for maneuvering large boats, like pontoons, around the marina.
  • Mikuni® Intake System: The lightweight Mikuni® long tube intake track system helps build low end torque.
  • Best In Class Fuel Efficiency: Lean Burn Control increases fuel efficiency by allowing combustion to operate on a leaner air/fuel mixture.
  • PGM-FI: Multi-port Programmed Fuel Injection adds both easy starts and improved fuel efficiency - without sacrificing performance.
  • Exceptional manuverability: Easy Dock Steering® takes the anxiety out of maneuvering your pontoon boat around the marina.
  • Proven Honda Quality: Our outboards share many technologies and components used in Honda vehicles, with all the benefits of years of proven Honda engineering, precision manufacturing and reliability.
  • Unmatched peace of mind: Honda's True 5 Warranty is the best in the business.
  • Engine Alert System: The Engine Alert System uses visual, audio and RPM reduction circuits to alert the operator of over-heating, low oil PSI and over-revving.
  • Honda Corrosion Protection: Our corrosion protection system includes a durable, multi-layered paint process, helping your Honda to continue to look and perform like new.
  • Additional Corrison Resistance: Sacrificial anodes and stainless steel technology, along with waterproof connectors, and internally painted cooling passages, all enhance corrosion protection.
  • Fresh Water Flushport: Fresh water flushport flushes debris and saltwater out of the engine.
  • Simplified maintenance: The little things make a big difference.
  • On-board connectivity: NMEA 2000 protocols allow engine data to be interfaced with on-board systems and systems displays, such as SONAR or GPS.
  • 3 Position Tiller Handle: The 3 Position Tiller Handle adjusts to your comfort for easiest hull maneuverability.
  • Variable Speed Trolling: Push button troll speed makes trolling easy, with 50 RPM increments from 750 rpm to 1000 rpm.
  • Easy Access Controls: The center mounted, ergonomically designed tiller handle is longer for improved handling.
  • High Output Charging System: There's always plenty of electric power with the BF60.
  • Neodymium Magnet Flywheel: Honda's exclusive neodymium magnet flywheel enables these engines to produce nearly twice as many charging amps as some competitors.
  • BF60 Charging: The standard BF60 develops a total 22 amps and 17 charging amps.
  • BFP60 Charging: The Power Thrust BFP60 develops a total 27 amps and 22 charging amps.
  • Tilt Limit Switch: An optional tilt limit switch keeps the motor from rubbing against the bottom of a pontoon boat's sun deck.
  • Rudder Angle Indicator: The dash mounted rudder angle indicator keeps the captain informed to which direction the engine is pointing.

Full specifications

Type
4-Stroke SOHC 3 Cylinder/12 Valves
Displacement
998 cc (61.0 cubic inches)
Bore & Stroke
73 mm x 79.5 mm (2.9 x 3.1 inches)
Full Throttle RPM Range
5,000-6,000 RPM
Rated Power
60 HP @ 5,500 RPM
Cooling System
Water Cooled
Fuel Delivery
Programmed Fuel Injection
Ignition System
MicroComputer Programmed
Starting System
Electric
Exhaust
Through Hub
Lubrication
Wet Sump
Trim Range
-4° to +16°
Tilt Range
60°
Steering Angle (to port and again to starboard)
50°
Gear Ratio
2.33:1
Gear Shift
F-N-R
Alternator
27-Amp
Battery Charging Power
22 Amp
Propeller
Optional
Power Tilt
NA
Power Trim & Tilt
Standard
Gas Assisted Tilt
NA
Oil Pressure Alert
Standard
Temperature Alert
Standard
Rev-Limiter
Standard
Speedometer Pickup
Standard
Recreational
5 years
Commercial/Rental
2 years
Optional Extended
Up to 36 months Learn More
Overall Width
417 mm/16.4 inches
L Type
531 mm/20 inches
X Type
658 mm/25 inches
L-Type
116 kg/256 lbs.
X-Type
123 kg/270 lbs.
